VWC-113-989-955 - 113-955-113 - 113955113 - COMPLETE 12V WIPER MOTOR AND LINKAGE ASSEMBLY - BEETLE 58-66 (WITH MODIFICATION) BEETLE 67-77 - SUPER BEETLE 71-72 - SEE ALL SPECIAL NOTES - SOLD AS ASSEMBLY
Manufacturer: Cip1 Five Star
Product Code: VWC-113-989-955
List Price: CAD $389.99
Our Price: CAD Sale: CAD $299.99
You Save CAD $90.00
Free Shipping over $99*
This aftermarket complete replacement wiper motor assembly can be used in any 12 volt standard Beetle 67-77 and Super Beetle 71-72 (Not 73-79 Super Beetle). This unit is a direct replacement for all standard 73-77 Beetles, if you plan to install this into an earlier year Beetle, you will need to also replace the wiper arms with new 73-77 wiper arms (SEE part number C24-111-955-407-8H). As you can see from the detailed photos (Click the LARGER PHOTO button above), this motor uses push-on connectors, so you will need to install a female wiring connector onto your original wiring and it may be necessary to extend some wires.
Special Note about setting the stop position: These motors are not pre-set in the park position. The nut that holds the small arm to the shaft sticking out of the motor is not tightened down. These are shipped loose from the factory. The shaft is a tapered fit and the arm needs to be adjusted to the correct position before it can be tightened.
Positioning the motor shut-off: You will need to ground the assembly and then apply power to either terminal 53 or 53b (doesnt matter which one). Once the motor is working, the power wire needs to be taken off 53 or 53b and put against terminal 53a to make it park and stop. Then tighten the nut and you are done.
Installation into your 58-66 Beetle that has been converted to 12-volt system: This can be done as the distance between the wiper shafts is the same on all 58-77 Beetle (15-3/4 inches). You will need to customize the wiring and the holes in the front cowl will need to be drilled slightly larger as the late model shafts are larger in diameter. These Grommets C16-311-261AW are required once holes drilled
