Description
6 Prong Version.
1/4" Terminals:
30 - Battery Power from the Headlight Switch
15 - Power to the Fuse Box
50 - Power to the Starter
X - Power To the Headlight Switch
30 - Battery Power from the Headlight Switch
15 - Power to the Fuse Box
50 - Power to the Starter
X - Power To the Headlight Switch
1/8" Terminals Not Typically Used:
P - Parking Position Power (NOT USED)
S - Ground Wire for Ignition Buzzer (Not typically used)
The 4 Prong version is available here: VWC-111-905-865-LGR P - Parking Position Power (NOT USED)
S - Ground Wire for Ignition Buzzer (Not typically used)
