Wiring Diagram Color Codes:
-
Red / Black: Rear Right Turn Signal
-
Green / Black: Front Right Turn Signal
-
Yellow / Black: Rear Left Turn Signal
-
Black / White: Front Left Turn Signal
-
Black / Green / White: Common to the Flasher
-
Grey / Black: Brake Lights (from Light Switch)
-
Brown Wires (2): Headlight Dimmer
